DUKE RIM LUCKY STAR ULTRA 28
DUKE RIMS LUCKY STAR Ultra 28 Aluminium, versatile made for XC and Gravel bike
The Lucky Star Ultra 28 is a lightweight pure XC aluminium rim. It is characterised by its unrivalled stiffness/weight and strength/weight ratios, thanks in part to the use of Dynamal aluminium.
DUKE has created an innovative profile, following its own experience with a very strict specification.This rim inaugurates a new modern geometry with an asymmetric profile and hookless walls.The rim holes are off-centre (offset), which makes it possible to close the spoke umbrella more tightly. This rim is more stable and increases the lateral stiffness of the wheel.The spoke tensions between the two plies are more balanced, which guarantees a better durability of the wheel.The hookless rim walls allow for both rim reinforcement and weight reduction.
DUKE owns its manufacturing tools.
Technology
-
Tubeless Ready
Tubeless Ready
Tubeless-compatible rim design
- Compatible with UST and Tubeless Ready standards
- Also compatible with tube-type (clincher) setups
Data sheet
- RIM MATERIAL
- ALU
- RIM PROFILE
- ASYMMETRICAL
- RIM HEIGHT (MM)
- 16
- SYSTEM MAX WEIGHT (KG)
- 95.0
- INSIDE WIDTH (MM)
- 28.0
- TYPE OF BRAKING
- DISC
- MAX STRAIN (N)
- 1050.0
- PRACTICE TYPE
- XC
- NIPPLE POSITION
- EXTERNAL
- NIPPLE HEIGHT (MM)
- 16.0
- REINFORCED RIM
- NO
- TYPE OF TYRE
- TUBELESS OU CHAMBRE À AIR
- VALVE HEIGHT (MM)
- 34
- TAPE WIDTH (MM)
- 30.0
- MAX PRESSURE (BAR)
- 2.8B WITH 2.25" TYRE
- ERD JANTE(S)
- LSU 28 29" : 605,5
- ETRTO (MM)
- 622.0
- RIM OFFSET (MM)
- 2.0
- MOUNTING WITH WASHERS
- YES (PILLAR 7048)
- POSITION
- FRONT
REAR - TYRE SECTION RANGE
- 42MM 1,65" / 64MM 2,50"
- STICKER TYPE
- L45
- RIM BRAND
- JANTE DUKE
- WARRANTY
- 2 YEARS
